Voice Tracker Array Microphone

Voice Tracker-01.jpg
Abstract Futuristic Background

Voice Tracker™ III

Array Microphone

The Voice Tracker III is ideal for our array microphone’s traditional applications of lecture and meeting recording, but improvements in VoIP products open the door for additional use in video conferencing and distance learning.

Features

  • Single, self-scanning “listening beam” automatically and electronically steered to the active talker, minimizing required setup

  • 360 degree field of view, but more sensitive from the front

  • Two stage noise reduction (spatial filtering and noise reduction processing)

  • 8 element, 22 inch long array for maximum range

  • 5 element LED display to indicate location of chosen talker

  • Ceiling/Wall mount and power converter from 120V AC to 6V DC included

Compatible with a variety of operating systems including:

  • Microsoft : Windows 3.x, Windows 95, Windows 98, Windows NT, Windows 2000, Windows ME, Windows XP, Windows Vista, Windows 7, Windows 10

  • Apple/Macintosh : Mac OS, Mac OS X

  • Linux

State of the art VoIP products like Zoom and Skype have improved AEC capability, so the Voice Tracker III doesn’t need its own AEC and consequently fills the need for an affordable yet high performance conferencing array microphone.

We opted to make the Voice Tracker III simple and easy to use. Just connect it to a wall power source and your computer thru a 3.5mm or USB connection and you are done. No multiple beam set up is required. The single “Listening Beam” automatically and electronically steers to the active talker. It is truly plug and play.

The decision not to add peripherals such as a camera or loudspeaker in our design enables the user to be free to choose best in class products, or to take advantage of existing equipment.

Multiple Voice Tracker III array microphones can be combined using 3.5mm Ys or Mixers. Use with High Performance mixers will lead to amazing room coverage and sound quality.

The Voice Tracker III can sit on a table or podium, but it also comes with a ceiling/wall mount. Because of its long pickup range, ceiling or wall mounting will work well and removes room clutter.

The Voice Tracker III is 22 inches long, 3 inches high (without the feet) and 2 inches thick.

Range:

  • 35+ feet for meeting recording (depends on acoustic characteristics of the room.)

Analog Output:

(6ft male/male audio cable included)

  • Mic level

  • Unbalanced

  • Stereo

  • 3.5mm mini-stereo jack

  • Same signal on tip & ring

  • 500 ohm output impedance

  • Easy conversion to USB audio using our USB converter (part 102A)

Physical Dimensions:

  • Length: 22″

  • Height: 3.25″ without feet, 4” with feet

  • Thickness: 1.5””

  • Weight: 1.5lbs

Power Equipment:

(wall-powered converter included)

  • 6V DC

  • 400 ma

  • Center Pin Positive

Frequency Response:

200Hz-7000Hz
+/-2.6dB
Measured at 12 feet on axis
